Product Summary

The M69000 is an accelerator with integrated memory.

Parametrics

M69000 absolute maximum ratings: (1)VCC Supply Voltage: min=-0.5V, max=5.0V; (2)VI Input Voltage: min=-0.5V, max=5.5V; (3)TSTG Storage Temperature: min=-40℃, max=125℃.

Features

M69000 features: (1)Display centering and stretching features for optimal fit of VGA graphics and text on 800×600 and 1024×768 panels; (2)Simultaneous Hardware Cursor and Pop-up Window: 64×64 pixels by 4 colors; 128×128 pixels by 2 colors; (3)PCI/Frame AGP Bus with Burst Mode capability and BIOS ROM support; (4)Power Sequencing control outputs regulate application of bias voltage, +5V to the panel and +12V to the inverter for backlight operation.; (5)3.3V Operation, 5.0V tolerant I/O.

Diagrams

M69000 block diagram
