MY4NJ AC220/240

function-filled miniature power relay, DIP, versatile, 100 mΩ, Safety standard approval

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.50~4.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.50~4.50

PartNumber:: MY4NJ AC220/240

Brand:: OMRON Corporation - Omron | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sue ouyang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-07

From Other Seller

Part Number:MY4NJ AC220/240
US $2.50 - 4.50
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MY4NJ AC220/240 is a versatile and function-filled miniature power relay for sequence control and power switching applications.

Parametrics

MY4NJ AC220/240 characteristics: (1)Contact resistance: 100 mΩ max.; (2)Operate time: 20 ms max.; (3)Release time: 20 ms max.; (4)Max. operating frequency: Mechanical: 18,000 operations/hr; Electrical: 1,800 operations/hr (under rated load); (5)Insulation resistance 1,000 MΩ min. (at 500 VDC); (6)Dielectric strength 2,000 VAC, 50/60 Hz for 1.0 min (1,000 VAC between contacts of same polarity); (7)Ambient temperature Operating: –55℃ to 70℃ (with no icing); (8)Ambient humidity Operating: 5% to 85%; (9)Weight: Approx. 35 g.

Features

MY4NJ AC220/240 features: (1)Models with lockable test buttons now available; (2)Arc barrier standard on 4-pole Relays; (3)Dielectric strength: 2,000 VAC (coil to contact); (4)Environment-friendly cadmium-free contacts; (5)Safety standard approvals obtained; (6)Wide range of Sockets (PY, PYF Series) and optional parts are available.; (7)Max. Switching Current: 2-pole: 10 A, 4-pole: 5 A; (8)Provided with nameplate.
