Product Summary

The SPP20N60C3 is a power transistor.

Parametrics

SPP20N60C3 absolute maximum ratings: (1)continuous drain current: TC=25℃:20.7A, TC=100℃:13.1A; (2)pulsed drain current:62.1A; (3)avalanche energy, single pulse:690mJ; (4)avalanche energy, repetitive tAR limited by Tjmax,ID=20A, VDD=50V:1mJ; (5)avalanche current, repetitive tAR limited by Tjmax:20A; (6)gate sourece voltage static:±20V; (7)gate sourece voltage AC:±30V; (8)power dissipation:208W; (9)operating and storage temperature:-55℃ to +150℃; (10)reverse diode dv/dt:15V/ns.

Features

SPP20N60C3 features: (1)new revolutionary high voltage technology; (2)worldwide best RDS(on) in TO220; (3)ultra low gate charge; (4)periodic avalanche rated; (5)extreme dv/dt rated; (6)high peak current capability; (7)improved transconductance; (8)PG-TO-220-3-31:fully isolated package; (9)Pb-free leading plating: ROHs compliant; (10)qualified according to JEDEC for target applications.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SPP20N60C3
SPP20N60C3
Infineon Technologies
MOSFET COOL MOS N-CH 650V
Data Sheet
0-1: $2.43
1-10: $2.14
10-100: $1.78
100-250: $1.21
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SPP20N60C3
SPP20N60C3
Infineon Technologies
MOSFET COOL MOS N-CH 650V
Data Sheet
0-1: $2.43
1-10: $2.14
10-100: $1.78
100-250: $1.21
