Product Summary
The ECW-U1105KCV is a Film Chip Capacitor. Stacked metallized PEN film as dielectric with simple mold-less construction. The applications of it include Coupling, By-pass, General purpose.
Parametrics
ECW-U1105KCV general specifications: (1)Category temp.range: 16VDC, 50VDC:–55℃ to +105℃, 100VDC, 250VDC:–40℃ to +85℃; (2)Rated voltage:16VDC, 50VDC, 100VDC, 250VDC; (3)Capacitance range:16VDC: 0.12 to 0.47 μF (E12),50VDC:0.056 to 0.22 μF (E12), 100VDC:0.012 to 1.0 μF (E12), 250VDC:0.001 to 1.0 μF (E12); (4)Capacitance tolerance: 16VDC,50VDC:±5%(J), 100VDC,250VDC: ±10%(K) (100VDC, C≤0.15 μF ±5%(J), ±10%(K)); (5)Withstand voltage: Between terminals, 16VDC, 50VDC : Rated volt. (VDC)5175% 1 to 5s, 100VDC, 250VDC : Rated volt. (VDC)5150% 60s; (6)Dissipation factor:≤1.0% (20℃,1kHz); (7)Insulation resistance:C≤0.33 μF: 16VDC:≥000MΩ(20℃,10VDC, 60s), 50VDC:≥3000MΩ(20℃,50VDC, 60s), 100VDC, 250VDC:≥3000MΩ(20℃,100VDC,60s);C>0.33μF:16VDC : 1000MΩ μF min.(20℃,10VDC, 60s),100VDC, 250VDC : 1000MΩ μF min.(20℃,100VDC,60s); (8)Soldering conditions: Reflow soldering 16VDC, 50VDC : 240℃ max. and 30 s max. at more than 210℃(Temp. at cap. surface), 100VDC, 250VDC : 230℃ max. and 30 s max. at more than 210℃(Temp.at cap.surface).
Features
ECW-U1105KCV features: (1)Small in size ; (2)Applicable for reflow soldering.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ECW-U1105KCV |
Panasonic Electronic Components |
Film Capacitors 1uF 100V 10% |
Data Sheet |
|
|
||||||||||||
