Product Summary

The 74HCT595D is an 8-bit serial-in/serial or parallel-out shift register with output latches. It is pin compatible with low power Schottky TTL(LSTTL). The 74HCT595D is specified in compliance with JEDEC standard no. 7A. The device has a serial input (DS) and a serial standard output (Q7’) for cascading. It is also provided with asynchronous reset (active LOW) for all 8 shift register stages. The applications of the 74HCT595D include Serial-to-parallel data conversion, Remote control holding register.

Parametrics

74HCT595D absolute maximum ratings: (1)supply voltage: 4.5V to 5.5V; (2)input voltage:0V to VCC; (3)output voltage:0V to VCC; (4)ambient temperature:-40℃ to +125℃; (5)input rise and fall time: VCC = 4.5 V:6.0ns to 500ns.

Features

74HCT595D features: (1)8-bit serial input; (2)8-bit serial or parallel output; (3)Storage register with 3-state outputs; (4)Shift register with direct clear; (5)100 MHz (typical) shift out frequency; (6)ESD protection:HBM EIA/JESD22-A114-A exceeds 2000 V, MM EIA/JESD22-A115-A exceeds 200 V.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
74HCT595D
74HCT595D

NXP Semiconductors

Counter Shift Registers 8BIT SHIFT REGISTER W/OUTPUT LATCH

Data Sheet

Negotiable
74HCT595D,112
74HCT595D,112

NXP Semiconductors

Counter Shift Registers 8BIT SHIFT REGISTER

Data Sheet

0-1: $0.25
1-25: $0.23
25-100: $0.21
100-250: $0.20
74HCT595D,118
74HCT595D,118

NXP Semiconductors

Counter Shift Registers 8-BIT SHIFT REG W/OUTPUT LATCH

Data Sheet

0-1: $0.25
1-25: $0.23
25-100: $0.21
100-250: $0.20
74HCT595DB,112
74HCT595DB,112

NXP Semiconductors

Counter Shift Registers 8-BIT SHIFT REG

Data Sheet

0-1: $0.71
1-25: $0.65
25-100: $0.57
100-250: $0.50
74HCT595DB,118
74HCT595DB,118

NXP Semiconductors

Counter Shift Registers 8-BIT SHIFT REG

Data Sheet

0-1430: $0.32
1430-2000: $0.32
2000-3000: $0.31
3000-6000: $0.30
74HCT595DB
74HCT595DB

NXP Semiconductors

Counter Shift Registers 8-BIT SHIFT REG W/OUTPUT LATCH

Data Sheet

Negotiable
74HCT595DB-T
74HCT595DB-T

NXP Semiconductors

Counter Shift Registers 8-BIT SHIFT REG W/OUTPUT LATCH

Data Sheet

Negotiable
