Product Summary
The BZX384-C33 is a Low-power voltage regulator diode, which is encapsulated in a very small SOD323 (SC-76) plastic SMD package. The BZX384-C33 is available in the normalized E24 ±2% (BZX384-B) and approx. ±5% (BZX384-C) tolerance range. The BZX384-C33 consists of 37 types with nominal working voltages from 2.4 to 75 V. The applications of the BZX384-C33 include General regulation functions.
Parametrics
BZX384-C33 absolute maximum ratings: (1)continuous forward current: 250 mA; (2)non-repetitive peak reverse power dissipation: 40 W at tp = 100 ms; square wave; Tamb = 25 ℃; prior to surge; (3)total power dissipation: 300 mW at Tamb = 25 ℃; (4)storage temperature: -65 to +150 ℃; (5)junction temperature: -65 to +150 ℃.
Features
BZX384-C33 features: (1)Total power dissipation: max. 300 mW; (2)Two tolerance series: ±2% and approx. ±5%; (3)Working voltage range: nominal 2.4 to 75 V (E24 range); (4)Non-repetitive peak reverse power dissipation: max. 40 W.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BZX384-C33 T/R |
NXP Semiconductors |
Zener Diodes DIODE ZENER 5 PCT TAPE-7 |
Data Sheet |
Negotiable |
|
||||||||||||
|
BZX384-C33,115 |
NXP Semiconductors |
Zener Diodes DIODE ZENER 5 PCT |
Data Sheet |
|
|
||||||||||||
