Product Summary

The LT6207CGN is a low cost quad voltage feedback amplifier that features 100MHz gain-bandwidth product, 450V/μs slew rate and 50mA output current. It has an input range that includes ground and an output that swings within 60mV of either supply rail, making them well suited for single supply operation. The LT6207CGN is available in the 16-pin SSOP package. It is specified over the commercial, industrial and automotive temperature ranges. The applications of the LT6207CGN include Video Line Driver, Automotive Displays, RGB Amplifiers, Coaxial Cable Drivers, Low Voltage High Speed Signal Processing.

Parametrics

LT6207CGN absolute maximum ratings: (1)Total Supply Voltage (V+ to V–):12.6V; (2)Input Current:±10mA; (3)Input Voltage Range:±VS ; (4)Output Short-Circuit Duration:Indefinite; (5)Pin Current While Exceeding Supplies:±25mA; (6)Operating Temperature Range:–40℃ to 85℃; (7)Specified Temperature Range:0℃ to 70℃; (8)Storage Temperature Range:–65℃ to 150℃; (9)Maximum Junction Temperature:150℃; (10)Lead Temperature (Soldering, 10 sec):300℃.

Features

LT6207CGN features: (1)450V/μs Slew Rate; (2)100MHz Gain Bandwidth Product; (3)Wide Supply Range 2.7V to 12.6V; (4)Output Swings Rail-to-Rail; (5)Input Common Mode Range Includes Ground; (6)High Output Drive: 50mA; (7)Channel Separation: 90dB at 10MHz; (8)Specified on 3V, 5V and ±5V Supplies; (9)Input Offset Voltage: 1mV; (10)Low Power Dissipation: 20mW per Amplifier on Single 5V; (11)Operating Temperature Range: –40℃ to 125℃; (12)Low Profile (1mm) SOT-23 (ThinSOT) Package.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LT6207CGN
LT6207CGN

IC OP AMP VIDEO QUAD 3V 16-SSOP
Data Sheet
0-4000: $0.99
LT6207CGN#PBF
LT6207CGN#PBF

IC OP AMP VIDEO QUAD 3V 16-SSOP
Data Sheet
0-1: $1.88
1-25: $1.25
25-100: $0.99
LT6207CGN#TR
LT6207CGN#TR

IC OPAMP VID QUAD 100MHZ 16-SSOP
Data Sheet
0-5000: $1.02
LT6207CGN#TRPBF
LT6207CGN#TRPBF

IC OP AMP VIDEO QUAD 3V 16-SSOP
Data Sheet
0-2500: $1.02
