Product Summary
The MURD620CTG is a switch mode Power Rectifier. It is designed for use in switching power supplies, inverters and as free wheeling diodes.
Parametrics
MURD620CTG absolute maximum ratings: (1)Peak Repetitive Reverse Voltage, VRRM: 200 V; (2)Working Peak Reverse Voltage, VRWM: 200 V; (3)DC Blocking Voltage, VR: 200 V; (4)Average Rectified Forward Current, IF(AV): 3.0A when (Rated VR, TC = 140℃) Per Diode; 6.0A when Per Device; (5)Peak Repetitive Forward Current, IF 6.0 A when (Rated VR, Square Wave, 20 kHz, TC = 145℃) Per Diode; (6)Non.Repetitive Peak Surge Current, IFSM: 50 A when (Surge Applied at Rated Load Conditions Halfwave, 60 Hz); (7)Operating Junction and Storage Temperature Range, TJ, Tstg: -65 to +175℃.
Features
MURD620CTG features: (1)Ultrafast 35 Nanosecond Recovery Time; (2)Low Forward Voltage Drop; (3)Low Leakage; (4)Pb-Free Packages are Available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MURD620CTG |
ON Semiconductor |
Rectifiers 200V 6A Ultrafast |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
MURD305RL |
ON Semiconductor |
Rectifiers REC 3A 50V ULTFST |
Data Sheet |
Negotiable |
|
||||||||||||
|
MURD310T4 |
ON Semiconductor |
Diodes (General Purpose, Power, Switching) REC 3A 100V ULTFST |
Data Sheet |
Negotiable |
|
||||||||||||
 |
MURD320 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
MURD320T4 |
ON Semiconductor |
Rectifiers 200V 3A Ultrafast |
Data Sheet |
Negotiable |
|
||||||||||||
|
MURD320T4G |
ON Semiconductor |
Rectifiers 200V 3A Ultrafast |
Data Sheet |
|
|
||||||||||||
|
MURD330T4 |
ON Semiconductor |
Rectifiers 300V 3A Ultrafast |
Data Sheet |
Negotiable |
|
||||||||||||
