Product Summary

The SII0680ACLU144 is a single-chip solution for a PCI to ATA controller. It accepts host commands through the PCI bus, processes them and transfers data between the host and ATA devices. The SII0680ACLU144 can be used to control two independent ATA channels: primary and secondary. Each channel has its own ATA bus and will support up to two ATA/ATAPI devices for a maximum of four devices. The SII0680ACLU144 supports up to a 133 MB/sec transfer rate exceeding that which is specified in ATA/ATAPI-6.

Parametrics

SII0680ACLU144 absolute maximum ratings: (1)VDDH Supply Voltage: 3.6 V; (2)VIN Input Voltage: -0.3 ~ 6.0 V; (3)IOUT DC Output Current: 16 mA; (4)TSTG Storage Temperature: -65 ~ 150 ℃.

Features

SII0680ACLU144 features: (1)Standalone PCI to ATA host controller chip; (2)Compliant with PCI Specification, revision 2.2; (3)Compliant with PCI IDE Controller Specification, revision 1.0; (4)Compliant with Programming Interface for Bus Master IDE Controller, revision 1.0; (5)Compliant with ATA/ATAPI-6 specifications; (6)Compliant with UDMA6 ATA/133 Specification; (7)Driver support for Win98, WinME, NT4, Win2K and XP.(IDE and RAID including Linux IDE support); (8)Supports up to 4Mbit external FLASH or EPROM for BIOS expansion.; (9)Supports an external EEPROM, FLASH or serial EPROM for programmable subsystem vendor ID and subsystem product ID; (10)Supports all necessary test requirements for WHQL; (11)Supports the Microsoft driver protocols for PIO and bus master DMA operations.

Diagrams

SII0680ACLU144 block diagram
