Product Summary

The 3362P-1-501LF is a Square Trimming Potentiometer.

Parametrics

3362P-1-501LF absolute maximum ratings: (1)Standard Resistance Range: 10 to 2 megohms; (2)Resistance Tolerance: ±10 % std.(tighter tolerance available); (3)Absolute Minimum Resistance: 1 % or 2 ohms(whichever is greater); (4)Contact Resistance Variation: 1 % or 3 ohms max.(whichever is greater); (5)Adjustability: Voltage:±0.05 %, Resistance: ±0.15 %, Resolution: Infinite; (6)Insulation Resistance: 500 vdc. 1,000 megohms min; (7)Dielectric Strength: Sea Level: 900 vac, 80,000 Feet: 350 vac; (8)Adjustment Angle: 240 °nom.

Features

3362P-1-501LF features: (1)Single-Turn / Cermet / Industrial / Sealed; (2)Miniature package; (3)Rotor designed for automatic machine adjust interface; (4)Withstands harsh environments and immersion cleaning processes; (5)Available on tape and reel packaging ; (6)RoHS compliant version available.

Diagrams

3362P-1-501LF block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
3362P-1-501LF
3362P-1-501LF

Bourns

Trimmer Resistors - Through Hole 1/4"SQ 500OHMS 10% 0.5WATTS

Data Sheet

0-1: $0.61
1-10: $0.56
10-50: $0.49
50-100: $0.43
