Product Summary

The SM8S36A-E3-2D is a surface mount automotive transient voltage suppressor.

Parametrics

Absolute maximum ratings: (1)Steady state power dissipation, PD: 8.0W; (2)Peak forward surge current, 8.3ms single half sine-wave, IFSM: 700A; (3)Typical thermal resistance junction to case, RθJC: 0.90℃/W; (4)Operating junction and storage temperature range, TJ, TSTG: -55 to +175℃.

Features

Features: (1)Ideally suited for load dump protection; (2)Plastic package has Underwriters Laboratory; (3)Flammability Classification 94V-0; (4)High temperature stability due to unique oxide passivation; (5)and patented PAR?construction; (6)Integrally molded heatsink provides a very low thermal resistance for maximum heat dissipation; (7)Low leakage current at TJ = 175℃; (8)High temperature soldering guaranteed: 260℃ for 10 seconds at terminals; (9)Meets ISO7637-2 surge spec; (10)Low forward voltage drop.
