Product Summary

The MURS120T3G is a Surface Mount Ultrafast Power Rectifier. The MURS120T3G is suited for high voltage, high frequency rectification, or as free wheeling and protection diodes in surface mount applications where compact size and weight are critical to the system.

Parametrics

MURS120T3G absolute maximum ratings: (1)Peak Repetitive Reverse Voltage:200V; (2)Working Peak Reverse Voltage:200V; (3)DC Blocking Voltage:200V; (4)Average Rectified Forward Current:1.0A @ TL = 155℃, 2.0A @ TL = 145℃; (5)Non-Repetitive Peak Surge Current,(Surge applied at rated load conditions halfwave, single phase, 60 Hz):40A; (6)Operating Junction Temperature:-65℃ to +175℃.

Features

MURS120T3G features: (1)Small Compact Surface Mountable Package with J-Bend Leads; (2)Rectangular Package for Automated Handling; (3)High Temperature Glass Passivated Junction; (4)Low Forward Voltage Drop (0.71 to 1.05 V Max @ 1.0 A, TJ=150℃); (5)Pb-Free Packages are Available.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MURS120T3G
MURS120T3G

ON Semiconductor

Rectifiers 200V 1A Ultrafast

Data Sheet

0-1: $0.28
1-25: $0.19
25-100: $0.15
100-500: $0.10
