SF5G42

silicon planar type, medium power control application, TO220

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~1.20

PartNumber:: SF5G42

Brand:: Toshiba Semiconductor - Toshiba | Pack: TO | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sue ouyang's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-11

From Other Seller

Part Number:SF5G42
US $0.30 - 1.20
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SF5G42 is a silicon planar type, medium power control applications.

Parametrics

SF5G42 maximum ratings: (1)R.M.S On.State Current IT (RMS): 7.8 A; (2)Peak One Cycle Surge On.State: 80 (50Hz)A; (3)Current (Non.Repetitive) ITSM: 88 (60Hz)A; (4)I2t Limit Value I2t: 32 A2s; (5)Peak Gate Power Dissipation PGM: 0.5 W; (6)Average Gate Power Dissipation PG (AV): 0.05 W; (7)Peak Forward Gate Voltage VFGM: 5 V; (8)Peak Reverse Gate Voltage VRGM: -5 V; (9)Peak Forward Gate Current IGM: 200 mA; (10)Junction Temperature Tj: -40~125 ℃; (11)Storage Temperature Range Tstg: -40~125 ℃.

Features

SF5G42 features: (1)Repetitive Peak Off.State Voltage: VDRM = 400, 600V; (2)Repetitive Peak Reverse Voltage: VRRM = 400, 600V; (3)Average On.State Current: IT(AV) = 5A; (4)JEDEC TO.220AB Package.
